Vertical Shaft Impact Crusher (Sand Making Machine)
PCL Series
Using the stone-on-stone autogenous crushing principle, this machine is suited to medium and fine crushing of hard and extra-hard materials such as ores, cement, refractories, calcined bauxite, corundum and glass raw material. Material forms a vortex between the impeller and the shell and is reduced by repeated mutual impact and abrasion.
- Stone-on-stone autogenous crushing gives good particle shape and grading
- Suited to hard and extra-hard materials, with long wear-part life
- Impeller speeds from 800 to 3000 r/min, adjustable to the material
Key features
- Stone-on-stone autogenous crushing gives good particle shape and grading
- Suited to hard and extra-hard materials, with long wear-part life
- Impeller speeds from 800 to 3000 r/min, adjustable to the material
- Capacities from 12 to 360 t/h across 7 models
- Dual-motor drive (2×30 up to 2×220 kW)
- Compact structure with few maintenance points
Specifications
Vertical Shaft Impact Crusher — PCL Series
| Model | Max feed size (mm) | Impeller speed (r/min) | Capacity (t/h) | Power (kW) | Weight (t) | Overall dimensions (mm) |
|---|---|---|---|---|---|---|
| PCL-600 | 30 | 2000–3000 | 12–30 | 2×30 | 5.6 | 2800 × φ1550 × 2030 |
| PCL-750 | 35 | 1500–2500 | 25–55 | 2×45 | 7.3 | 3300 × φ1800 × 2440 |
| PCL-900A | 40 | 1200–2000 | 55–100 | 2×55 | 12.1 | 3750 × φ2120 × 2660 |
| PCL-900B | 40 | 1000–1450 | 65–130 | 2×75 | 13.6 | 3750 × φ2300 × 2090 |
| PCL-1050 | 45 | 1000–1700 | 100–160 | 2×(90–110) | 16.9 | 4480 × φ2450 × 3906 |
| PCL-1250 | 45 | 850–1450 | 160–300 | 2×(132–180) | 22 | 4563 × φ2650 × 3716 |
| PCL-1350 | 50 | 800–1193 | 200–360 | 2×(180–220) | 26 | 5340 × φ2940 × 3650 |
Selection note：The tables above list standard PCL series parameters. Impeller speed and capacity vary with material hardness and feed size. For an accurate selection, please provide your material type, feed size and target capacity.
Applications
- Medium and fine crushing and sand making of various ores
- Cement and refractory materials
- Calcined bauxite and corundum
- Glass raw material processing
- Manufactured sand for construction
Options & configuration
- Motor power matched to each model
- Impeller speed adjustable to the material
- Supporting equipment: vibrating feeder, vibrating screen, sand washer, belt conveyor
- Optional mobile chassis
- Optional centralized lubrication system
Need help choosing a model?
Tell us the material and the target capacity — we will recommend the model and the supporting equipment that fit.
