Raymond Mill
3R / 4R / 5R / 6R Series Raymond Mill
A vertical pendulum roller mill. The rollers are pressed outward against the grinding ring by centrifugal force, and the material is ground by rolling contact. Product fineness is adjustable from 80 to 400 mesh, with some materials reaching 500 mesh. It handles non-metallic minerals and chemical raw materials below Mohs 7 and 6% moisture, and is one of the most widely used milling machines in the industry.
- Vertical layout with a small footprint; a complete system from lump feed to finished powder
- Very uniform product with a high screening pass rate — hard to match with other mill types
- Sealed gearbox and belt drive for smooth, reliable transmission
Key features
- Vertical layout with a small footprint; a complete system from lump feed to finished powder
- Very uniform product with a high screening pass rate — hard to match with other mill types
- Sealed gearbox and belt drive for smooth, reliable transmission
- Quality steel in the main structure and high-performance wear material on the wearing parts
- Centralised electrical control; the milling workshop can run essentially unattended
- 80–400 mesh adjustable through the classifier, without changing parts
Specifications
3R / 4R / 5R / 6R Series Raymond Mill
| Model | Max. Feed Size (mm) | Product Size (mm) | Capacity (t/h) | Center Shaft Speed (r/min) | Grinding Ring ID (mm) | Roller Diameter (mm) | Main Motor (kW) |
|---|---|---|---|---|---|---|---|
| 3R1410 | 5–8 | 0.125–0.044 | 1–10 | 280 | Φ405 | Φ140 | 7.5 |
| 3R2615 | 20 | 0.125–0.044 | 2–25 | 170 | Φ780 | Φ260 | 18.5 |
| 3R2714 | 20 | 0.125–0.044 | 2–28 | 170 | Φ830 | Φ270 | 18.5 |
| 4R2714 | 15–25 | 0.125–0.044 | 3–30 | 170 | Φ830 | Φ270 | 22 |
| 3R3016 | 15–25 | 0.125–0.044 | 3–34 | 178 | Φ910 | Φ300 | 30 |
| 4R3016 | 15–25 | 0.125–0.044 | 3–36 | 178 | Φ910 | Φ300 | 30 |
| 4R3216 | 25 | 0.125–0.044 | 3–38 | 130 | Φ970 | Φ320 | 37 |
| 5R4119 | 30 | 0.125–0.044 | 6–76 | 105 | Φ1280 | Φ410 | 75 |
| 6R4525 | 30 | 0.125–0.044 | 10–120 | 82 | Φ1770 | Φ450 | 132 |
Selection note：Parameters above are standard industry figures. Capacity varies considerably with material hardness, moisture, feed size and target fineness, so the table gives typical ranges. Final selection is confirmed by a material test and the contract.
Applications
- Barite, calcite, potash feldspar, talc and marble
- Limestone, dolomite, fluorite, lime and activated clay
- Activated carbon, bentonite, kaolin, cement, phosphate rock and gypsum
- Glass and insulation material raw feed
- Fine powder processing of over 300 materials across the chemical and building-materials industries
Options & configuration
- Models 3R / 4R / 5R / 6R, selected against capacity and fineness
- Variable-frequency classifier for fineness control
- Complete line with jaw crusher, bucket elevator, electromagnetic feeder, cyclone collector and pulse dust filter
- Dust collection configured to local environmental requirements
- Centralised control cabinet
